Contract manufacturing with passion
Discover our wide range of services
Are you looking for a partner for individual and repeat production of your components? Then we can certainly help you! Contract manufacturing from Bleichert offers
- highly qualified personnel with extensive know-how
- an extensive range of machinery
- the fastest possible response times and a solution concept for your requirements
- up-to-date certificates and approvals
Data. Calculation. Production. Delivery.
Simply send us your data in the appropriate format. Our team will then provide you with a non-binding quote. Simply use the contact field at the bottom of this page for your inquiry!
What we offer:
Our extensive range is described below. Click on the relevant tab for more details:
LASER CUTTING
| Bezeichnung | Ausprägung |
|---|---|
| Machinery: | TRUMPF Trumatic L 3030 - 4kW |
| Workspace: | 3.000 x 1.500 mm |
| Maximum part size: | 2.970 x 1.470mm (Large size); 2.470 x 1220mm (Medium size); 1970 x 970mm (small size) |
| Laser output: | 4.000 Watt |
| Max. sheet thickness: | Structural steel 20mm |
| Data requirements: | 3D model in .STP or .SLDPRT |
| Optional: | Drawing in .TIF or .PDF |
CUTTING
Aluminum cutting
Kaltenbach SKL 450 H
Semi-automatic metal circular saw for aluminum
| Arbeitsbereich | Material | Gradzahl | Daten |
|---|---|---|---|
| Work area: | Circular material: | 90° | 160mm |
| Square bar material: | 90° | 145mm | |
| Profiles: | 90° | 320 x 50mm | |
| Lying profiles: | 45° | 250 x 40mm | |
| Vertical profiles: | 45° | 100 x 150mm |
- Measuring length up to 6,000mm
- Semi-automatic material feed
Steel cutting
Kaltenbach KKS 400 EC-H
Cold circular saw
| Arbeitsbereich | Material | Gradzahl | Daten |
|---|---|---|---|
| Working area: | Circular material: | 90° | 30mm |
| Square bar material: | 90° | 30mm | |
| Profiles: | 90° | 100 x 100mm | |
| Horinzontal profiles: | 45° | 100 x 100mm | |
| Vertical profiles: | 45° | 100 x 100mm |
- Measuring length up to 4,000mm
Behringer HBP 313 A/G
High-performance automatic band saw
| Arbeitsbereich | Material | Gradzahl | Daten |
|---|---|---|---|
| Working area: | Circular material: | 90° | 280 mm |
| Square bar material: | 90° | 280 x 280mm | |
| Min. material dimension | Square bar | 12mm | |
| Flat material | 10x8mm | ||
| Min. length | 15mm |
- Raw material length max. 12000
- Measuring length up to 8000mm
- Semi-automatic material feed
Round cut
Behringer HBP 310 A
High-performance automatic band saw
| Arbeitsbereich | Material | Gradzahl | Daten |
|---|---|---|---|
| Working area: | Circular material: | 90° | 250 mm |
| Square bar material: | 90° | 250 x 250mm | |
| Min. material dimension | Circular material | Ø12 | |
| Length | Min. 15mm Max. 500mm |
- Raw material length 6000mm
Semi-automatic material feed
TILT
AMADA HFE3i 2204L
Folding press
| Information | Daten |
|---|---|
| Pressing power | 220t |
| Folding length | 4200mm |
| Maximum sheet thickness | 10mm (depending on bending length) |
- CAM-programming AMADA VPSS 3i BEND
- Use of 2D and 3D drawings
- Feasibility studies
Required data: 3D model in .STP or .SLDPRT
Optional: Drawing in .TIF or .PDF
DRILLING
ELHA R60/2000
Radial drilling machine
| Information | Daten |
|---|---|
| Drilling performance in steel | Ø 60mm |
| Drilling performance in cast iron | Ø 80mm |
| Reaming performance in steel | Ø 100mm |
| Drilling performance in cast iron | Ø 120mm |
| Thread cutting in steel | M60 |
| Thread cutting in cast iron | M72 |
| Mounting surface | 2125x1100mm |
Alzmetall ALZRAPID 32
Radial drilling machine
| Information | Daten |
|---|---|
| Drilling performance in steel | Ø 25mm |
| Drilling performance in cast iron | Ø 32mm |
| Thread cutting in steel | M24 |
| Thread cutting in cast iron | M30 |
| Mounting surface | 1175x525mm |
Donau Donauflex 145
Radial drilling machine
| Information | Daten |
|---|---|
| Drilling performance in steel | Ø 45mm |
| Drilling performance in cast iron | Ø 55mm |
| Thread cutting in steel | M36 |
| Thread cutting in cast iron | M45 |
| Mounting surface | 1800x600mm |
Quickboy
Thread tapping machine
| Information | Daten |
|---|---|
| Drilling performance in steel | M5-M20 |
LATHE
Star SV-32
Sliding headstock automatic lathe
| Information | Daten |
|---|---|
| Max. Machining diameter | 30mm |
| Max. Headstock stroke | 300mm |
| Max. Machining length | 1500mm |
Traub TND 400
CNC Lathe
| Information | Daten |
|---|---|
| Spindle bore | 65mm |
| Length of rotation | 800mm |
| Clamping range | 10 - 300mm |
DMG NEF 400
CNC Lathe machine
| Information | Daten |
|---|---|
| Spindle bore | 65mm |
| Length of rotation | 650mm |
| Clamping range | 10 - 200mm |
Colchester Magnum
Conventional turning machine
| Information | Daten |
|---|---|
| Spindle bore | 54mm |
| Length of rotation | 1100mm |
| Clamping range | 10 - 200mm |
MILLING
Bimatec-Soraluce SL10000
5-Achs CNC-Bed milling machine
| Information | Daten |
|---|---|
| Travel distances: | X=8500mm |
| Y=1300mm | |
| Z=1600mm | |
| Clamping weight: | Max. 5000kg |
AXA VHC 2 1760S
Moving column machining center
| Information | Daten |
|---|---|
| Travel distance: | X=1760mm |
| Y=500mm | |
| Z=600mm | |
| Swivel head: | A=+-90°(2,5° Split) |
| Turntable: | Ø700mm |
Hedelius RS505-K
5-Achs CNC-Milling machine
| Information | Daten |
|---|---|
| Travel distance: | X=1000mm |
| Y=510mm/315mm | |
| Z=480mm | |
| A=+10° bis -100° | |
| C=360° | |
| Clamping weight | Max. 200kg |
WELDING
Welding process: 135 Metall Active gas welding(MAG)
Information Daten DATEN 2
Welding table size: 1500x3000mm (2x) H: max. 1000mm
1250x2500mm (2x) H: max. 1500mm
Component weight Max. 1000kg
PAINTING
LUTRO Painting and drying system
| Information | Daten |
|---|---|
| Component dimensions LxWxH: | Max. 5500x3000x2400mm |
